MORITEX茉丽特 远心镜头 MML08-ST65
MORITEX茉丽特 远心镜头 MML08-ST65 规格 Spec MML08-ST65 Coaxial Illumination - Magnification 0.80±5% WD (mm) 65 Resolution (μm) 12.4 Depth of Field (mm) 1.86 NA 0.027 Effective Fno 14.9 Distortion (%) 0.003 Weight (g) 44 Largest Compatible Sensor 1/2" type Mount C mount * Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)* Resolution values indicate the theoretical resolution at a wavelength of 550nm. 0755-84690029 手机/微信：13682357734 QQ:2844337877...
分类：
描述
MORITEX茉丽特 远心镜头 MML08-ST65
规格
|
Spec |
MML08-ST65 |
|
Coaxial Illumination |
- |
|
Magnification |
0.80±5% |
|
WD (mm) |
65 |
|
Resolution (μm) |
12.4 |
|
Depth of Field (mm) |
1.86 |
|
NA |
0.027 |
|
Effective Fno |
14.9 |
|
Distortion (%) |
0.003 |
|
Weight (g) |
44 |
|
Largest Compatible Sensor |
1/2" type |
|
Mount |
C mount |
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
