MORITEX茉丽特 远心镜头 MML1-ST150
规格
Spec |
MML1-ST150 |
Coaxial Illumination |
- |
Magnification |
1.00±5% |
WD (mm) |
156 |
Resolution (μm) |
8.8 |
Depth of Field (mm) |
1.05 |
NA |
0.038 |
Effective Fno |
13 |
Distortion (%) |
0.067 |
Weight (g) |
84 |
Largest Compatible Sensor |
1/2" type |
Mount |
C mount |
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
