MORITEX茉丽特 远心镜头 MML1-ST300D
MORITEX茉丽特 远心镜头 MML1-ST300D 规格 Spec MML1-ST300D Coaxial Illumination ○ Magnification 1.00±5% WD (mm) 305 Resolution (μm) 16.6-21.5 Depth of Field (mm) 1.98-2.56 NA 0.020-0.016 Effective Fno 24.72-32 Distortion (%) -0.019 Weight (g) 150 Largest Compatible Sensor 1/2" type Mount C mount * Resolution values indicate the theoretical resolution at a wavelength of 550nm.* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm) 0755-84690029 手机/微信：13682357734 QQ:2844337877...
分类：
描述
MORITEX茉丽特 远心镜头 MML1-ST300D
规格
|
Spec |
MML1-ST300D |
|
Coaxial Illumination |
○ |
|
Magnification |
1.00±5% |
|
WD (mm) |
305 |
|
Resolution (μm) |
16.6-21.5 |
|
Depth of Field (mm) |
1.98-2.56 |
|
NA |
0.020-0.016 |
|
Effective Fno |
24.72-32 |
|
Distortion (%) |
-0.019 |
|
Weight (g) |
150 |
|
Largest Compatible Sensor |
1/2" type |
|
Mount |
C mount |
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
