MORITEX茉丽特 远心镜头 MML2-ST110DS

规格

Spec

MML2-ST110DS

Coaxial Illumination

Magnification

2.00±5%

WD (mm)

112

Resolution (μm)

11.2

Depth of Field (mm)

0.66

NA

0.03

Effective Fno

33.2

Distortion (%)

0.024

Weight (g)

39

Largest Compatible Sensor

1/2" type

Mount

C mount

* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
