MORITEX茉丽特 远心镜头 MML3-ST110DS
MORITEX茉丽特 远心镜头 MML3-ST110DS 规格 Spec MML3-ST110DS Coaxial Illumination ○ Magnification 3.00±5% WD (mm) 108.3 Resolution (μm) 11.2 Depth of Field (mm) 0.44 NA 0.03 Effective Fno 49.7 Distortion (%) 0.022 Weight (g) 43 Largest Compatible Sensor 1/2" type Mount C mount * Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)* Resolution values indicate the theoretical resolution at a wavelength of 550nm. 0755-84690029 手机/微信:13682357734 QQ:2844337877...
分类:
描述
MORITEX茉丽特 远心镜头 MML3-ST110DS
规格
Spec |
MML3-ST110DS |
Coaxial Illumination |
○ |
Magnification |
3.00±5% |
WD (mm) |
108.3 |
Resolution (μm) |
11.2 |
Depth of Field (mm) |
0.44 |
NA |
0.03 |
Effective Fno |
49.7 |
Distortion (%) |
0.022 |
Weight (g) |
43 |
Largest Compatible Sensor |
1/2" type |
Mount |
C mount |
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
