MORITEX茉丽特 远心镜头 MML05-ST300D
规格
|
Spec |
MML05-ST300DVI |
|
Coaxial Illumination |
○ |
|
Magnification |
0.50±5% |
|
WD (mm) |
348 |
|
Resolution (μm) |
15.3-37.3 |
|
Depth of Field (mm) |
3.6-8.9 |
|
NA |
0.022-0.009 |
|
Effective Fno |
11.4-27.8 |
|
Distortion (%) |
0.06 |
|
Weight (g) |
200 |
|
Largest Compatible Sensor |
1/2" type |
|
Mount |
C mount |
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
