MORITEX茉丽特 远心镜头 MML08-ST110D
规格
|
Spec |
MML08-ST110D |
|
Coaxial Illumination |
○ |
|
Magnification |
0.80±5% |
|
WD (mm) |
110 |
|
Resolution (μm) |
13.5 |
|
Depth of Field (mm) |
2 |
|
NA |
0.024 |
|
Effective Fno |
16.1 |
|
Distortion (%) |
0.005 |
|
Weight (g) |
85 |
|
Largest Compatible Sensor |
1/2" type |
|
Mount |
C mount |
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
