MORITEX茉丽特 远心镜头 MML08-ST170
MORITEX茉丽特 远心镜头 MML08-ST170 规格 Spec MML08-ST170 Coaxial Illumination - Magnification 0.80±5% WD (mm) 172.9 Resolution (μm) 12 Depth of Field (mm) 1.79 NA 0.028 Effective Fno 14 Distortion (%) 0.067 Weight (g) 76 Largest Compatible Sensor 1/2" type Mount C mount * Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)* Resolution values indicate the theoretical resolution at a wavelength of 550nm. 0755-84690029 手机/微信：13682357734 QQ:2844337877...
分类：
描述
MORITEX茉丽特 远心镜头 MML08-ST170
规格
|
Spec |
MML08-ST170 |
|
Coaxial Illumination |
- |
|
Magnification |
0.80±5% |
|
WD (mm) |
172.9 |
|
Resolution (μm) |
12 |
|
Depth of Field (mm) |
1.79 |
|
NA |
0.028 |
|
Effective Fno |
14 |
|
Distortion (%) |
0.067 |
|
Weight (g) |
76 |
|
Largest Compatible Sensor |
1/2" type |
|
Mount |
C mount |
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
