MORITEX茉丽特 远心镜头 MML8-ST110
规格
|
Spec |
MML8-ST110 |
|
Coaxial Illumination |
- |
|
Magnification |
8.00±5% |
|
WD (mm) |
109.4 |
|
Resolution (μm) |
7.5 |
|
Depth of Field (mm) |
0.16 |
|
NA |
0.045 |
|
Effective Fno |
88.4 |
|
Distortion (%) |
-0.021 |
|
Weight (g) |
49 |
|
Largest Compatible Sensor |
1/2" type |
|
Mount |
C mount |
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
* Resolution values indicate the theoretical resolution at a wavelength of 550nm
