MORITEX茉丽特 远心镜头 MML1-ST40
MORITEX茉丽特 远心镜头 MML1-ST40 规格 Spec MML1-ST40 Coaxial Illumination - Magnification 1.00±5% WD (mm) 40 Resolution (μm) 7.2 Depth of Field (mm) 0.88 NA 0.046 Effective Fno 11 Distortion (%) -0.038 | -0.443 Weight (g) 26 Largest Compatible Sensor 1/2" type | 2/3” type Mount C mount Remarks 2/3” type spec are reference values *Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)*Resolution values indicate the theoretical resolution at a wavelength of 550nm. 0755-84690029 手机/微信：13682357734 QQ:2844337877...
分类：
描述
MORITEX茉丽特 远心镜头 MML1-ST40
规格
|
Spec |
MML1-ST40 |
|
Coaxial Illumination |
- |
|
Magnification |
1.00±5% |
|
WD (mm) |
40 |
|
Resolution (μm) |
7.2 |
|
Depth of Field (mm) |
0.88 |
|
NA |
0.046 |
|
Effective Fno |
11 |
|
Distortion (%) |
-0.038 | -0.443 |
|
Weight (g) |
26 |
|
Largest Compatible Sensor |
1/2" type | 2/3” type |
|
Mount |
C mount |
|
Remarks |
2/3” type spec are reference values |
*Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
*Resolution values indicate the theoretical resolution at a wavelength of 550nm.
