MORITEX茉丽特 远心镜头 MML2-ST40
MORITEX茉丽特 远心镜头 MML2-ST40 规格 Spec MML2-ST40 Coaxial Illumination - Magnification 2.00±5% WD (mm) 40.1 Resolution (μm) 4.8 Depth of Field (mm) 0.29 NA 0.07 Effective Fno 14.3 Distortion (%) 0.032 | -0.138 Weight (g) 29 Largest Compatible Sensor 1/2" type | 2/3” type Mount C mount Remarks 2/3” type spec are reference values *Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)*Resolution values indicate the theoretical resolution at a wavelength of 550nm. 0755-84690029 手机/微信：13682357734 QQ:2844337877...
分类：
描述
MORITEX茉丽特 远心镜头 MML2-ST40
规格
|
Spec |
MML2-ST40 |
|
Coaxial Illumination |
- |
|
Magnification |
2.00±5% |
|
WD (mm) |
40.1 |
|
Resolution (μm) |
4.8 |
|
Depth of Field (mm) |
0.29 |
|
NA |
0.07 |
|
Effective Fno |
14.3 |
|
Distortion (%) |
0.032 | -0.138 |
|
Weight (g) |
29 |
|
Largest Compatible Sensor |
1/2" type | 2/3” type |
|
Mount |
C mount |
|
Remarks |
2/3” type spec are reference values |
*Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
*Resolution values indicate the theoretical resolution at a wavelength of 550nm.
