MORITEX茉丽特 远心镜头 MML3-ST40D
规格
|
Spec |
MML3-ST40D |
|
Coaxial Illumination |
○ |
|
Magnification |
3.00±5% |
|
WD (mm) |
37.9 |
|
Resolution (μm) |
4.8 |
|
Depth of Field (mm) |
0.19 |
|
NA |
0.07 |
|
Effective Fno |
21.3 |
|
Distortion (%) |
-0.147 | -0.322 |
|
Weight (g) |
33 |
|
Largest Compatible Sensor |
1/2" type | 2/3” type |
|
Mount |
C mount |
|
Remarks |
2/3” type spec are reference values |
*Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2" CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
*Resolution values indicate the theoretical resolution at a wavelength of 550nm.
**: Made-to-order product
