MORITEX茉丽特 远心镜头 MML1.5-HR65
MORITEX茉丽特 远心镜头 MML1.5-HR65 规格 Spec MML1.5-HR65 Coaxial Illumination - Magnification 1.5±5% WD (mm) 65.1 Resolution (μm) 5.4 Depth of Field (mm) 0.42 NA 0.063 Effective Fno 12 Distortion (%) -0.11 Weight (g) 46 Largest Compatible Sensor 1/2" Mount C mount 0755-84690029 手机/微信：13682357734 QQ:2844337877 邮箱：2844337877@qq.com
分类：
描述
MORITEX茉丽特 远心镜头 MML1.5-HR65
规格
|
Spec |
MML1.5-HR65 |
|
Coaxial Illumination |
- |
|
Magnification |
1.5±5% |
|
WD (mm) |
65.1 |
|
Resolution (μm) |
5.4 |
|
Depth of Field (mm) |
0.42 |
|
NA |
0.063 |
|
Effective Fno |
12 |
|
Distortion (%) |
-0.11 |
|
Weight (g) |
46 |
|
Largest Compatible Sensor |
1/2" |
|
Mount |
C mount |
