MORITEX茉丽特 远心镜头 MML1.5-HR110D
规格
|
Spec |
MML1.5-HR110D |
|
Coaxial Illumination |
○ |
|
Magnification |
1.50±5% |
|
WD (mm) |
111.1 |
|
Resolution (μm) |
5.4 |
|
Depth of Field (mm) |
0.42 |
|
NA |
0.063 |
|
Effective Fno |
12 |
|
Distortion (%) |
0.076 |
|
Weight (g) |
110 |
|
Largest Compatible Sensor |
2/3" type |
|
Mount |
C mount |
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2 CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
