MORITEX茉丽特 远心镜头 MML1-HR110
MORITEX茉丽特 远心镜头 MML1-HR110 规格 Spec MML1-HR110 Coaxial Illumination - Magnification 1.00±5% WD (mm) 110 Resolution (μm) 7.4 Depth of Field (mm) 0.88 NA 0.045 Effective Fno 11 Distortion (%) 0.011 Weight (g) 110 Largest Compatible Sensor 2/3" type Mount C mount * Resolution values indicate the theoretical resolution at a wavelength of 550nm.* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2 CCD camera. (Permissible circle of confusion on the image-formation side: 40μm) 0755-84690029 手机/微信：13682357734 QQ:2844337877 邮箱：2844337877@qq.com...
分类：
描述
MORITEX茉丽特 远心镜头 MML1-HR110
规格
|
Spec |
MML1-HR110 |
|
Coaxial Illumination |
- |
|
Magnification |
1.00±5% |
|
WD (mm) |
110 |
|
Resolution (μm) |
7.4 |
|
Depth of Field (mm) |
0.88 |
|
NA |
0.045 |
|
Effective Fno |
11 |
|
Distortion (%) |
0.011 |
|
Weight (g) |
110 |
|
Largest Compatible Sensor |
2/3" type |
|
Mount |
C mount |
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2 CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
