MORITEX茉丽特 远心镜头 MML2-HR110D
MORITEX茉丽特 远心镜头 MML2-HR110D 规格 Spec MML2-HR110D Coaxial Illumination ○ Magnification 2.00±5% WD (mm) 110 Resolution (μm) 4.5 Depth of Field (mm) 0.27 NA 0.074 Effective Fno 13.5 Distortion (%) -0.039 Weight (g) 110 Largest Compatible Sensor 2/3" type Mount C mount * Resolution values indicate the theoretical resolution at a wavelength of 550nm.* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2 CCD camera. (Permissible circle of confusion on the image-formation side: 40μm) 0755-84690029 手机/微信：13682357734 QQ:2844337877 邮箱：2844337877@qq.com...
分类：
描述
MORITEX茉丽特 远心镜头 MML2-HR110D
规格
|
Spec |
MML2-HR110D |
|
Coaxial Illumination |
○ |
|
Magnification |
2.00±5% |
|
WD (mm) |
110 |
|
Resolution (μm) |
4.5 |
|
Depth of Field (mm) |
0.27 |
|
NA |
0.074 |
|
Effective Fno |
13.5 |
|
Distortion (%) |
-0.039 |
|
Weight (g) |
110 |
|
Largest Compatible Sensor |
2/3" type |
|
Mount |
C mount |
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2 CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
