MORITEX茉丽特 远心镜头 MML4-HR65
MORITEX茉丽特 远心镜头 MML4-HR65 规格 Spec MML4-HR65 Coaxial Illumination - Magnification 4±5% WD (mm) 65 Resolution (μm) 3 Depth of Field (mm) 0.09 NA 0.112 Effective Fno 17.9 Distortion (%) 0.005 Weight (g) 86 Largest Compatible Sensor 2/3" Mount C mount * Resolution values indicate the theoretical resolution at a wavelength of 550nm.* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2 CCD camera. (Permissible circle of confusion on the image-formation side: 40μm) 0755-84690029 手机/微信：13682357734 QQ:2844337877 邮箱：2844337877@qq.com...
分类：
描述
MORITEX茉丽特 远心镜头 MML4-HR65
规格
|
Spec |
MML4-HR65 |
|
Coaxial Illumination |
- |
|
Magnification |
4±5% |
|
WD (mm) |
65 |
|
Resolution (μm) |
3 |
|
Depth of Field (mm) |
0.09 |
|
NA |
0.112 |
|
Effective Fno |
17.9 |
|
Distortion (%) |
0.005 |
|
Weight (g) |
86 |
|
Largest Compatible Sensor |
2/3" |
|
Mount |
C mount |
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2 CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
