MORITEX茉丽特 远心镜头 MML08-HR65
规格
|
Spec |
MML08-HR65 |
|
Coaxial Illumination |
- |
|
Magnification |
0.8±5% |
|
WD (mm) |
65 |
|
Resolution (μm) |
8.4 |
|
Depth of Field (mm) |
1.2 |
|
NA |
0.04 |
|
Effective Fno |
9.9 |
|
Distortion (%) |
0.013 |
|
Weight (g) |
60 |
|
Largest Compatible Sensor |
2/3" |
|
Mount |
C mount |
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2 CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
