MORITEX茉丽特 远心镜头 MML08-HR110
MORITEX茉丽特 远心镜头 MML08-HR110 规格 Spec MML08-HR110 Coaxial Illumination - Magnification 0.80±5% WD (mm) 110 Resolution (μm) 9.3 Depth of Field (mm) 1.38 NA 0.036 Effective Fno 11 Distortion (%) -0.025 Weight (g) 109 Largest Compatible Sensor 2/3" type Mount C mount 0755-84690029 手机/微信：13682357734 QQ:2844337877 邮箱：2844337877@qq.com
分类：
描述
MORITEX茉丽特 远心镜头 MML08-HR110
规格
|
Spec |
MML08-HR110 |
|
Coaxial Illumination |
- |
|
Magnification |
0.80±5% |
|
WD (mm) |
110 |
|
Resolution (μm) |
9.3 |
|
Depth of Field (mm) |
1.38 |
|
NA |
0.036 |
|
Effective Fno |
11 |
|
Distortion (%) |
-0.025 |
|
Weight (g) |
109 |
|
Largest Compatible Sensor |
2/3" type |
|
Mount |
C mount |
