MORITEX茉丽特 远心镜头 MML044-SR130VI-18C
MORITEX茉丽特 远心镜头 MML044-SR130VI-18C 规格 Spec MML044-SR130VI-18C Magnification x 0.44 WD (mm) 130 Resolution (μm) 12.0 - 24.0 Depth of Field (mm) 3.314 - 6.616 NA 0.014 - 0.028 Effective Fno 8.02 - 16.01 Distortion (%) 0.012 Weight (g) 350 IF (mm) 18.5(1.1") Mount C mount * Resolution values indicate the theoretical resolution at a wavelength of 550nm.* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2 CCD camera. (Permissible circle of confusion on the image-formation side: 40μm) 0755-84690029 手机/微信：13682357734 QQ:2844337877 邮箱：2844337877@qq.com...
分类：
描述
MORITEX茉丽特 远心镜头 MML044-SR130VI-18C
规格
|
Spec |
MML044-SR130VI-18C |
|
Magnification x |
0.44 |
|
WD (mm) |
130 |
|
Resolution (μm) |
12.0 - 24.0 |
|
Depth of Field (mm) |
3.314 - 6.616 |
|
NA |
0.014 - 0.028 |
|
Effective Fno |
8.02 - 16.01 |
|
Distortion (%) |
0.012 |
|
Weight (g) |
350 |
|
IF (mm) |
18.5(1.1") |
|
Mount |
C mount |
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2 CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
