MORITEX茉丽特 远心镜头 MML075-SR110DVI-18C
MORITEX茉丽特 远心镜头 MML075-SR110DVI-18C 规格 Spec MML075-SR110DVI-18C Magnification x 0.75 WD (mm) 110 Resolution (μm) 6.3 - 19.7 Depth of Field (mm) 0.997 - 3.129 NA 0.017 - 0.053 Effective Fno 7.00 - 22.00 Distortion (%) -0.055 Weight (g) 400 IF (mm) 18.5(1.1") Mount C mount * Resolution values indicate the theoretical resolution at a wavelength of 550nm.* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2 CCD camera. (Permissible circle of confusion on the image-formation side: 40μm) 0755-84690029 手机/微信：13682357734 QQ:2844337877 邮箱：2844337877@qq.com...
分类：
描述
MORITEX茉丽特 远心镜头 MML075-SR110DVI-18C
规格
|
Spec |
MML075-SR110DVI-18C |
|
Magnification x |
0.75 |
|
WD (mm) |
110 |
|
Resolution (μm) |
6.3 - 19.7 |
|
Depth of Field (mm) |
0.997 - 3.129 |
|
NA |
0.017 - 0.053 |
|
Effective Fno |
7.00 - 22.00 |
|
Distortion (%) |
-0.055 |
|
Weight (g) |
400 |
|
IF (mm) |
18.5(1.1") |
|
Mount |
C mount |
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2 CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
