MORITEX茉丽特 远心镜头 MML0275-SR130VI-18C
MORITEX茉丽特 远心镜头 MML0275-SR130VI-18C 规格 Spec MML0275-SR130VI-18C Magnification x 0.275 WD (mm) 130 Resolution (μm) 19.7 - 55.9 Depth of Field (mm) 8.463 - 25.156 NA 0.017 - 0.006 Effective Fno 8.00 - 23.78 Distortion (%) 0.034 Weight (g) 520 IF (mm) 18.5 (1.1") Mount C mount * Resolution values indicate the theoretical resolution at a wavelength of 550nm.* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2 CCD camera. (Permissible circle of confusion on the image-formation side: 40μm) 0755-84690029 手机/微信：13682357734 QQ:2844337877 邮箱：2844337877@qq.com...
分类：
描述
MORITEX茉丽特 远心镜头 MML0275-SR130VI-18C
规格
|
Spec |
MML0275-SR130VI-18C |
|
Magnification x |
0.275 |
|
WD (mm) |
130 |
|
Resolution (μm) |
19.7 - 55.9 |
|
Depth of Field (mm) |
8.463 - 25.156 |
|
NA |
0.017 - 0.006 |
|
Effective Fno |
8.00 - 23.78 |
|
Distortion (%) |
0.034 |
|
Weight (g) |
520 |
|
IF (mm) |
18.5 (1.1") |
|
Mount |
C mount |
* Resolution values indicate the theoretical resolution at a wavelength of 550nm.
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2 CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
