MORITEX茉丽特 远心镜头 MML4-HR65DVI-5M
MORITEX茉丽特 远心镜头 MML4-HR65DVI-5M 规格 Spec MML4-HR65DVI-5M Coaxial Illumination ○ Magnification 4.00±5% WD (mm) 65 Resolution (μm) 2.0-8.2 Depth of Field (mm) 0.060-0.240 NA 0.167-0.041 Effective Fno 12.10-48.60 Distortion (%) 0.029 Weight (g) 285 Largest Compatible Sensor 2/3" Mount C mount 0755-84690029 手机/微信：13682357734 QQ:2844337877 邮箱：2844337877@qq.com
分类：
描述
MORITEX茉丽特 远心镜头 MML4-HR65DVI-5M
规格
|
Spec |
MML4-HR65DVI-5M |
|
Coaxial Illumination |
○ |
|
Magnification |
4.00±5% |
|
WD (mm) |
65 |
|
Resolution (μm) |
2.0-8.2 |
|
Depth of Field (mm) |
0.060-0.240 |
|
NA |
0.167-0.041 |
|
Effective Fno |
12.10-48.60 |
|
Distortion (%) |
0.029 |
|
Weight (g) |
285 |
|
Largest Compatible Sensor |
2/3" |
|
Mount |
C mount |
